10508B-104, brass reusable crimp fitting.

Item Specifications

• A Dimension (inch)
  1.69"
• A Dimension (mm)
  42.92 mm
• Angle Shape
  straight
• Compatible Hose ID (mm)
  mm
• Construction Style
  reusable
• End Type 1
  Male pipe (NPTF)
• Hose Cut Off Factor (inch)
  0.97"
• Hose Cut Off Factor (mm)
  24.79 mm
• Hose Size
  -4
• Inside Diameter (inch)
  0.34"
• Inside Diameter (mm)
  8.63 mm
• Maximum Working Temperature (C°)
  150 °C
• Maximum Working Temperature (F°)
  302 °F
• Minimum Working Temperature (C°)
  -40 °C
• Minimum Working Temperature (F°)
  -40 °F
• Product Height (inch)
  0.56"
• Product Height (mm)
  14.224 mm
• Product Length (inch)
  1.7"
• Product Length (mm)
  43.18 mm
• Product Material
  brass
• Product Width (inch)
  0.56"
• Product Width (mm)
  14.224 mm
• Series
  105 B
• Thread Size 1
  1/4-18 NPTF
